EZM114-125
| Principal | |
|---|---|
| Product | Meter Center Branch Unit |
| Current Rating | 125 A |
| Type | Meter-Pak |
| Bus Rating | 800 A |
| Number of Jaws | 4 without jaw release |
| Number of Meter Sockets | 4 |
| Bypass Type | No bypass |
| Socket Type | Ringed |
| Opcionales | |
|---|---|
| Certifications | Registrado por UL |
| Busbar Material | Aluminio embarrado eléctrico |
| Enclosure Material | Acero |
| Enclosure Rating | NEMA 3R |
| Maximum Voltage Rating | 120/240 V AC |
| Mounting | Superficie |
| Phase | 1 fase in1 fase out |
| Wire Configuration | 3-hilos |
| altura | 1222.25 mm |
| anchura | 311.15 mm |
| profundidad | 180.09 mm |
| Packing Units | |
|---|---|
| Tipo de Unidad de Paquete 1 | PCE |
| Número de Unidades en el Paquete 1 | 1 |
| Paquete 1 Peso | 25.5 kg |
| Paquete 1 Altura | 122.2 cm |
| Paquete 1 ancho | 31.1 cm |
| Paquete 1 Largo | 18 cm |
| Offer Sustainability | |
|---|---|
| Reglamento REACh | Declaración de REACh |
| Directiva RoHS UE | Conforme Declaración RoHS UE |
| Sin mercurio | Sí |
| Información sobre exenciones de RoHS | Sí |
